User Manual of DS-7100HWI/HVI-SL/SH and DS-7200HI-SL Series DVR
74
Figure 6.27 Interface of Playback by Tag with Video List
Figure 6.28 Toolbar of Playback by Tag
Table 6.5 Detailed Explanation of Playback-by-tag Toolbar
Button
Operation
Button
Operation
Button
Operation
Button
Operation
/
Audio on/Mute
/
Start/Stop clipping
30s forward
30s reverse
Add default tag
Add customized tag
Tag
management
Slow forward
/
Pause reverse
play/Reverse play/
Single-frame reverse
play
/
Pause
play/Play/Single-frame
play
Stop
Fast forward
Previous tag
Next tag
Tag search
Exit
Hide
Progress bar
Video type
bar
 Playback progress bar: use the mouse to click any point of the progress bar or drag the progress bar to
locate special frames.
 About video type bar: represents normal recording (manual or schedule); represents event
recording (motion); represents smart search recording.
