Digital Video Recorder User Manual
178
Figure 10-5 Set Line Crossing Detection Rules
Step 7 Click and set two points in the preview window to draw a virtual line.
You can use the to clear the existing virtual line and re-draw it.
Up to 4 rules can be configured.
Figure 10-6 Draw Line for Line Crossing Detection
Step 8 Click Apply to activate the settings.
The sudden scene change detection and the line crossing detection cannot be enabled at the same
channel.
10.4 Intrusion Detection
Purpose
Intrusion detection function detects people, vehicle or other objects which enter and loiter in a
pre-defined virtual region, and some certain actions can be taken when the alarm is triggered.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HIKVISION DS-7104HGHI-F1/N and is the answer not in the manual?

HIKVISION DS-7104HGHI-F1/N Specifications

General IconGeneral
Power consumption (typical)8 W
Voltage12 V
Product colorWhite
Channels quantity4 channels
Audio formats supportedG.711
Video compression formatsH.264, H.264+
BNC input ports1
USB 2.0 ports quantity2
Ethernet LANYes
Number of users128 user(s)
Ethernet interface typeFast Ethernet
Supported network protocolsTCP/IP, PPPoE, DHCP, Hik-connect Cloud P2P, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP, HTTPS
Maximum HDD capacity6000 GB
Operating temperature (T-T)-10 - 55 °C
Operating relative humidity (H-H)10 - 90 %
Weight and Dimensions IconWeight and Dimensions
Width200 mm
Height45 mm
Weight800 g
