Figure 5-13 Region Exing Detecon
2. Select a camera.
3. Turn on Enable.
4. Set detecon rules and detecon areas.
1) Set Arming Area. Up to 4 arming areas are selectable.
2) Set
Sensivity. The higher the value is, the easier the detecon alarm can be triggered. Its
range is [1-100].
3)
Oponal: Set Target Detecon as Human or Vehicle to discard alarms which are not
triggered by human body or vehicle.
4) Click Draw Area to draw a quadrilateral
detecon region.
5. Set the arming schedule. Refer to for Congure Arming Schedule for details.
6. Set the linkage
acons. Refer to Congure Alarm Linkage Acon for details.
7. Click Apply.
Congure
Arming Schedule
Steps
1. Select Arming Schedule.
2. Choose one day of a week and set the
me segment. Up to eight me periods can be set within
each day.
Note
Time periods shall not be repeated or overlapped.
