User Manual of DS-7200-ST Series DVR
72
Figure 8. Alarm Management Menu
2. Select the Alarm Input No. and click the Set button to enter the Alarm Input Settings menu, shown
in Figure 9.
Figure 9. Alarm Management Settings
3. Set the alarm input type to be Normally Opened (N.O) or Normally Closed (N.C).
4. Check the checkbox next to Setting and click the Handle button to enter the Alarm Input Handle
menu.
5. Select the Triggered Camera tab.
6. Select cameras to trigger for recording when alarm occurs by checking the checkboxes under the
desired cameras, as shown in Figure 10.
Figure 10. Triggered Cameras Menu
