HIKVISION DS-7208HGHI-F1 User Manual

Digital Video Recorder User Manual
105
Figure 5-6 Sub-Stream Encoding
2) Select a camera in the camera dropdown list.
3) Configure the parameters.
4) Click Apply to save the settings.
5) (Optional) If the parameters can also be used to other cameras, click Copy to copy the
settings to other channels.

For DS-7200/7300/7600/8100/9000HUHI-F/N series, when 3 MP signal input is connected,
the resolution of sub-stream does not support QVGA/QCIF. It will adjust to CIF
automatically in this condition.

For DS-7200/7300/7600/8100/9000HUHI-F/N series, when 3 MP signal input is connected,
the frame rate of sub-stream cannot exceed 15 fps.

For HQHI-F/N series, when 3 MP signal input is connected, the frame rate of sub-stream
cannot exceed 12 fps.
Step 2 Set parameters for capture.
1) Select the Capture tab.
Figure 5-7 Capture Settings
2) Select a camera in the camera dropdown list.
3) Configure the parameters.
4) Click Apply to save the settings.
5) (Optional) If the parameters can also be used to other cameras, click Copy to copy the
settings to other channels.

HIKVISION DS-7208HGHI-F1 Specifications

General

Product color	Black
Rack capacity	1U
Channels quantity	8 channels
Remote control type	128
Video capturing speed	30 fps
Audio formats supported	G.711
Maximum video resolution	1920 x 1080 pixels
Video compression formats	H.264, H.264+
Playback resolutions supported	1080p lite
BNC input ports	8
USB 2.0 ports quantity	2
Ethernet LAN	Yes
Ethernet interface type	Fast Ethernet
Supported network protocols	TCP/IP, PPPoE, DHCP, Hik Cloud P2P, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP, HTTPS
HDD interface	Serial ATA
Maximum HDD capacity	6000 GB
Power consumption (typical)	12 W
Storage temperature (T-T)	10 - 90 °C
Operating temperature (T-T)	-10 - 55 °C

Weight and Dimensions

Weight	1000 g
Dimensions (WxDxH)	260 x 222 x 45 mm
