HIKVISION DS-7208HGHI-F1 User Manual

Digital Video Recorder User Manual
29
Table 1-5 Description of Front Panel
No.
Name
Function Description
1
Status
Indicators
ALARM
Turns red when a sensor alarm is detected.
READY
Turns blue, indicating that the DVR is functioning
properly.
STATUS
Turns blue when device is controlled by an IR
remote.
Turns red when controlled by a keyboard and
purple when IR remote and keyboard is used at the
same time.
HDD
Flickers in red when data is being read from or
written to HDD.
Tx/Rx
Flickers in blue when network connection is
functioning properly.
GUARD
Turns blue when the device is in armed status; at
this time, an alarm is enabled when an event is
detected.
Turns off when the device is unarmed. The
arm/disarm status can be changed by pressing and
holding on the ESC button for more than 3 seconds
in live view mode.
2
Alphanumeric Buttons
Switches to the corresponding channel in live view
or PTZ control mode.
Inputs numbers and characters in edit mode.
Switches between different channels in playback
mode.
Turns blue when the corresponding channel is
recording; turns red when the channel is in network
transmission status; turns pink when the channel is
recording and transmitting.

HIKVISION DS-7208HGHI-F1 Specifications

General

Product color	Black
Rack capacity	1U
Channels quantity	8 channels
Remote control type	128
Video capturing speed	30 fps
Audio formats supported	G.711
Maximum video resolution	1920 x 1080 pixels
Video compression formats	H.264, H.264+
Playback resolutions supported	1080p lite
BNC input ports	8
USB 2.0 ports quantity	2
Ethernet LAN	Yes
Ethernet interface type	Fast Ethernet
Supported network protocols	TCP/IP, PPPoE, DHCP, Hik Cloud P2P, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP, HTTPS
HDD interface	Serial ATA
Maximum HDD capacity	6000 GB
Power consumption (typical)	12 W
Storage temperature (T-T)	10 - 90 °C
Operating temperature (T-T)	-10 - 55 °C

Weight and Dimensions

Weight	1000 g
Dimensions (WxDxH)	260 x 222 x 45 mm
