Digital Video Recorder User Manual
33
Figure 1-7 Front Panel of DS-9000HUHI-F8/N
Front Panel 8:
Figure 1-8 Front Panel of DS-9000HUHI-F16/N
Table 1-6 Description of Front Panel
Turns red when a sensor alarm is detected.
Turns blue, indicating that the DVR is functioning
properly.
Turns blue when device is controlled by an IR remote.
Turns red when controlled by a keyboard and purple
when IR remote and keyboard is used at the same
time.
Flickers in red when data is being read from or written
to HDD.
Flickers in blue when network connection is
To Next Page
