Digital Video Recorder User Manual
124
Figure 5-40 Advanced Settings (for HQHI and HGHI-F series DVR)
Figure 5-41 Advanced Settings (for HUHI series DVR)
Step 3 Click Disable to disable H.264+ for all the analog cameras and the following attention box
pops up.
Figure 5-42 Attention Box
Step 4 Click Yes to enable the function and reboot the device to have new settings taken effect.
If H.264+ is already disabled for all the analog cameras, when you click Disable button, the
following attention box pops up to remind you that H.264+ is already disabled for all analog
cameras.
Figure 5-43 Attention Box
5.12 Configuring 1080P Lite
Purpose
When the 1080P Lite Mode is enabled, the encoding resolution at 1080P Lite (real-time) is
supported. If not, up to 1080P (non-real-time) is supported.
This chapter is appplicable to HQHI and HGHI-F series DVR.
 For HQHI series DVR:
Task1: Enabling the 1080P Lite Mode

HIKVISION DS-7316HQHI-F4/N Specifications

General

Product color	Black
Audio output channels	1.0 channels
Video compression formats	H.264
BNC input ports	1
Video input channels	16 channels
USB 2.0 ports quantity	2
Ethernet LAN	Yes
Ethernet interface type	Gigabit Ethernet
Supported network protocols	TCP/IP, PPPoE, DHCP, Hik Cloud P2P, DNS, DDNS, NTP, SADP, SMTP, SNMP, NFS, iSCSI, UPnP, HTTPS
HDD interface	Serial ATA
Maximum HDD capacity	6000 GB
Power consumption (typical)	45 W
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Dimensions (WxDxH)	445 x 390 x 70 mm
