Digital Video Recorder User Manual
80
Multi-Screen
Adjust the screen layout by selecting from the dropdown list.
For DS-7300/8100/9000HUHI-F/N series DVR, if the sum of the analog
and IP channels exceeds 25, up to 32-window division mode is
supported for the VGA/HDMI1 output.
Previous
Screen
Switch to the previous screen.
Next Screen
Switch to the next screen.
Start/Stop
Auto-Switch
Enable/disable the auto-switch of the screens.
The dwell time of the live view configuration must be set before using
Start Auto-Switch.
Start
Recording
Start recording of all channels, Continuous Record and
Motion Detection Record are selectable from the dropdown
list.
Add IP
Camera
A shortcut to enter the IP camera management interface.(For
HDVR series only)
Playback
Enter the playback interface and start playing back the video
of the selected channel immediately.
PTZ Control
A shortcut to enter the PTZ control interface of the selected
camera.
Output
Mode
Output Mode is configurable with Standard, Bright, Gentle
and Vivid options.
Aux Monitor
Switch to the auxiliary output mode and the operation for the
main output is disabled.
If you enter Aux monitor mode and the Aux monitor is not connected,
the mouse operation is disabled. You need to switch back to the Main
output with the F1 button on front panel or VOIP/MON button on IR
remote control and then press the Enter button.
