Specifications
Specifications of DS-8600NI-E8
Model
DS-8608NI-E8
DS-8616NI-E8
DS-8632NI-E8
Video/Audio
input
IP video input
8-ch
16-ch
32-ch
Two-way audio
1-ch, RCA (2.0 Vp-p, 1KΩ)
Network
Incoming bandwidth
50Mbps
100Mbps
200Mbps
Outgoing bandwidth
80Mbps
Remote connection
128
Video/Audio
output
Recording resolution
6MP/5MP/3MP/1080P/UXGA/720P/VGA/4CIF/DCIF/2CIF/CIF/QCIF
Frame rate
Main stream: 50 fps (P) / 60 fps (N)
Sub-stream: 50 fps (P) / 60 fps (N)
HDMI/VGA output
1-ch, resolution:
1920 × 1080P /60Hz, 1600 × 1200 /60Hz, 1280 × 1024 /60Hz, 1280 × 720
/60Hz, 1024 × 768 /60Hz
Audio output
1-ch, RCA (Linear, 1KΩ)
Decoding
Live view / Playback
resolution
6MP/5MP/3MP/1080P/UXGA/720P/VGA/4CIF/DCIF/2CIF/CIF/QCIF
Capability
8-ch@720P,
6-ch@1080P
16-ch@4CIF, 12-ch@720P, 6-ch@1080P
Hard disk
SATA
8 SATA interfaces for 4 HDDs + 1 DVD-R/W (default), or 8HDDs
eSATA (Optional)
1 eSATA interface
Capacity
Up to 4TB capacity for each HDD
External
interface
Network interface
2 RJ-45 10 /100 /1000 Mbps self-adaptive Ethernet interfaces
Serial interface
RS-232 and RS-485
USB interface
2 × USB 2.0 + 1 × USB 3.0
Alarm in / out
16 / 4 (optionally can be expanded to 16 / 8)
Others
Power supply
100 ~ 240 VAC
Consumption
(without hard disk or
DVD-R/W)
≤ 20 W
≤ 20 W
≤ 20 W
Working
temperature
-10 ºC ~ +55 ºC (14ºF ~ 131ºF)
Working humidity
10 % ~ 90 %
Chassis
19-inch rack-mounted 2U chassis
Dimensions
(W × D × H)
445 × 470 ×70 mm ( 17.5"× 18.5" × 2.8")
Weight
(without hard disk or
DVD-R/W )
≤ 8 kg (17.6 lb)

HIKVISION DS-7604NI-SE/P Specifications

General

Product color	Black
Channels quantity	4 channels
Playback resolutions supported	5MP, 3MP, 1080p, UXGA, 720p, VGA, 4CIF, DCIF, 2CIF, CIF, QCIF
Audio input	1
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	5
Ethernet interface type	Fast Ethernet, Gigabit Ethernet
HDD capacity	1000 GB
HDD interface	Serial ATA
Maximum HDD capacity	4000 GB
Power consumption (typical)	15 W
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Weight	2000 g
Dimensions (WxDxH)	445 x 290 x 45 mm
