HIKVISION DS-7604NI-SE/P Quick Operation Guide

Quick Operation Guide of Network Video Recorder
32
Specifications of DS-7600NI-SN
Model
DS-7604NI-SN
DS-7608NI-SN
DS-7616NI-SN
Video/Audio
input
IP video input
4-ch
8-ch
16-ch
Two-way audio input
1-ch, RCA (2.0 Vp-p, 1kΩ)
Network
Incoming bandwidth
25Mbps
50Mbps
100Mbps
Outgoing bandwidth
40Mbps
Remote connection
32
128
128
Video/Audio
output
HDMI/VGA output
1-ch, resolution:
1920 × 1080P /60Hz, 1280 × 1024 /60Hz, 1280 × 720 /60Hz, 1024 × 768 /60Hz
Audio output
1-ch, RCA (Linear, 1kΩ)
Decoding
Playback / Live view
resolution
1080P / 720P / VGA / 4CIF / DCIF / 2CIF / CIF / QCIF
Capability
4-ch@720P ,
2-ch@1080P
8-ch@4CIF,
4-ch@720P ,
2-ch@1080P
8-ch@4CIF,
8-ch@720P ,
4-ch@1080P
Hard disk
SATA
1 SATA interface for 1 HDD
2 SATA interface for 2
HDDs
Capacity
Up to 4TB for each disk
External
interface
Network interface
1 RJ-45 10 /100 Mbps self-adaptive Ethernet interface
1 RJ-45 10 /100 /1000
Mbps self-adaptive
Ethernet interface
USB interface
2 × USB 2.0
Alarm in/out
(Optional)
4 / 1
Others
Power supply
12VDC
Consumption
(without hard disk)
≤ 6W
≤ 10W
≤ 15W
Working
temperature
-10 ºC ~ +55 ºC (14ºF ~ 131ºF)
Working humidity
10 % ~ 90 %
Chassis
1U chassis
Dimensions
(W × D × H)
315 × 230 × 45 mm (12.4" × 9.0" × 1.8")
Weight
(without hard disk)
≤ 1 Kg (2.2 lb)

HIKVISION DS-7604NI-SE/P Specifications

General

Product color	Black
Channels quantity	4 channels
Playback resolutions supported	5MP, 3MP, 1080p, UXGA, 720p, VGA, 4CIF, DCIF, 2CIF, CIF, QCIF
Audio input	1
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	5
Ethernet interface type	Fast Ethernet, Gigabit Ethernet
HDD capacity	1000 GB
HDD interface	Serial ATA
Maximum HDD capacity	4000 GB
Power consumption (typical)	15 W
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Weight	2000 g
Dimensions (WxDxH)	445 x 290 x 45 mm
