Specifications of DS-7100NI-SN/P
Model
DS-7104NI-SN/P
DS-7108NI-SN/P
DS-7116NI-SN/P
Video/Audio
input
IP video input
4-ch
8-ch
16-ch
Two-way audio input
1-ch, RCA (2.0 Vp-p, 1kΩ)
Network
Incoming bandwidth
25Mbps
50Mbps
100Mbps
Outgoing bandwidth
40Mbps
Remote connection
32
128
128
Video/Audio
output
Recording resolution
1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
HDMI/VGA output
1-ch, resolution:
1920 × 1080P /60Hz, 1280 × 1024 /60Hz, 1280 × 720 /60Hz, 1024 × 768 /60Hz
Audio output
1-ch, RCA (Linear, 1kΩ)
Playback resolution
1080P /UXGA /720P /VGA /4CIF /DCIF /2CIF /CIF /QCIF
Synchronous playback
4-ch@720P,
2-ch@1080P
8-ch@4CIF, 4-ch@720P, 2-ch@1080P
Hard disk
SATA
1 SATA interface for 1 HDD
Capacity
Up to 4TB for each disk
External
interface
Network interface
1 RJ-45 10 /100 Mbps self-adaptive Ethernet
interface
1 RJ-45 10 /100/1000
Mbps self-adaptive
Ethernet interface
USB interface
2 × USB 2.0
PoE
Interface
4 independent 10 /100
Mbps PoE Ethernet
interfaces
8 independent 10 /100 Mbps PoE Ethernet
interfaces
Max. Power
35W
100W
Supported Standard
AF
Others
Power supply
48VDC
Consumption
(without hard disk)
≤ 50 W
≤ 120 W
Working temperature
-10 ºC ~ +55 ºC (+14 ºF ~ +131 ºF)
Working humidity
10 % ~ 90 %
Chassis
1U chassis
Dimensions
(W × D × H)
205 × 205 × 45 mm
(8.1 × 8.1 × 1.8 inch)
285 × 210 × 45 mm (11.2 ×8.3 ×1.8 inch )
Weight
≤ 1 Kg ( without hard disk)

HIKVISION DS-7604NI-SE/P Specifications

General

Product color	Black
Channels quantity	4 channels
Playback resolutions supported	5MP, 3MP, 1080p, UXGA, 720p, VGA, 4CIF, DCIF, 2CIF, CIF, QCIF
Audio input	1
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	5
Ethernet interface type	Fast Ethernet, Gigabit Ethernet
HDD capacity	1000 GB
HDD interface	Serial ATA
Maximum HDD capacity	4000 GB
Power consumption (typical)	15 W
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Weight	2000 g
Dimensions (WxDxH)	445 x 290 x 45 mm
