HIKVISION DS-7604NI-SE/P Quick Operation Guide

Quick Operation Guide of Network Video Recorder
30
Specifications of DS-7600NI-E2/P and DS-7600NI-E1/P
Model
DS-7604NI-E1/
4P
DS-7608NI-E2/
8P
DS-7616NI-E2/
8P
DS-7632NI-E2/
8P
Video/Audio
input
IP video input
4-ch
8-ch
16-ch
32-ch
Two-way audio
input
1-ch, RCA (2.0 Vp-p, 1kΩ)
Network
Incoming bandwidth
25Mbps
50Mbps
100Mbps
200Mbps
Outgoing bandwidth
80Mbps
Remote connection
32
128
128
128
Video/Audio
output
Recording resolution
6MP/5MP/3MP/1080P/UXGA/720P/VGA/4CIF/DCIF/2CIF/CIF/QCIF
Frame rate
Main stream: 50 fps (P) / 60 fps (N)
Sub-stream: 50 fps (P) / 60 fps (N)
HDMI/VGA output
1-ch, resolution:
1920 × 1080P /60Hz, 1600 × 1200 /60Hz, 1280 × 1024 /60Hz, 1280 × 720 /60Hz,
1024 × 768 /60Hz
Audio output
1-ch, RCA (Linear, 1kΩ)
Decoding
Live view / Playback
resolution
6MP/5MP/3MP/1080P/UXGA/720P/VGA/4CIF/DCIF/2CIF/CIF/QCIF
Capability
4-ch@1080P
8-ch@720P,
6-ch@1080P
16-ch@4CIF, 12-ch@720P,
6-ch@1080P
Hard disk
SATA
1 SATA interface
for 1 HDD
2 SATA interfaces for 2 HDDs
Capacity
Up to 4TB for each disk
External
interface
Network interface
1 RJ-45 10 /100 /1000 Mbps self-adaptive Ethernet interface
USB interface
1 × USB 2.0 and 1 × USB 3.0
Alarm in/out
(Optional)
4 / 1
PoE
Interface
4 independent 100
Mbps PoE
network interfaces
8 independent 100 Mbps PoE network interfaces
Max. Power
50W
120W
Supported standard
AF and AT
Others
Power supply
48V DC
220V AC
Consumption
(without hard disk
and PoE)
≤ 10W
Working
temperature
-10 ºC ~ +55 ºC (+14 ºF~ + 131 ºF)
Working humidity
10 % ~ 90 %
Chassis
1U chassis
19-inch rack-mounted 1U chassis
Dimensions
(W × D × H)
315 × 230 × 45mm
(12.4"×9.1"×1.8")
445 × 290 × 45mm (17.5" × 11.4" × 1.8")
Weight
(without hard disk)
≤ 1 kg (2.2 lb)

HIKVISION DS-7604NI-SE/P Specifications

General

Product color	Black
Channels quantity	4 channels
Playback resolutions supported	5MP, 3MP, 1080p, UXGA, 720p, VGA, 4CIF, DCIF, 2CIF, CIF, QCIF
Audio input	1
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	5
Ethernet interface type	Fast Ethernet, Gigabit Ethernet
HDD capacity	1000 GB
HDD interface	Serial ATA
Maximum HDD capacity	4000 GB
Power consumption (typical)	15 W
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Weight	2000 g
Dimensions (WxDxH)	445 x 290 x 45 mm
