HIKVISION DS-7608NI-L1/W Quick Start Guide

Chapter 1 Rear Panel Interfaces Description
The rear panel interfaces vary with different models. Refer to the following table for common
interfaces description.
Table 1-1 Common Interfaces Description of Rear Panel
Item
Description
Item
Description
AUDIO IN
RCA connector for audio
input.
AUDIO OUT
RCA connector for audio
output.
LINE IN
RCA connector for two-way
audio input.
USB
Universal Serial Bus (USB)
interface for additional device.
VGA
DB15 connector for local
video output and menu
display.
HDMI
HDMI interface for video
output.
RS-485
RS-485 serial interface for
pan/tilt unit, speed dome, etc.
RS-232
RS-232 interface for
parameter configuration, or
transparent channel.
LAN
RJ-45 self-adaptive Ethernet
interface.
eSATA
Storage and expansion
interface for record or backup.
ALARM
IN/OUT
Alarm input/output interface.
GND
Ground.
Power Switch
Switch for turning on/off the
device.
Power Supply
100 to 240 VAC, 48 VDC, or 12
VDC power supply, different
models vary.
Wi-Fi antenna interface.

HIKVISION DS-7608NI-L1/W Specifications

General

Brand	HIKVISION
Model	DS-7608NI-L1/W
Category	Network Hardware
Language	English
