HIKVISION DS-7608NI-Q2/8P User Manual

Network Video Recorder User Manual
19
Table 1-4 IR Remote Functions
No.
Name
Function Description
1
POWER
ON/OFF
• To Turn Power On:
- If User Has Not Changed the Default NVR Device ID# (255):
1. Press Power On/Off button (1).
- If User Has Changed the NVR Device ID#:
1. Press DEV button.
2. Press Number buttons to enter user-defined Device ID#.
3. Press Enter button.
4. Press Power button to start device.
• To Turn NVR Off:
- If User Is Logged On:
1. Hold Power On/Off button (1) down for five seconds to
display the “Yes/No” verification prompt.
2. Use Up/Down Arrow buttons (12) to highlight desired
selection.
3. Press Enter button (12) to accept selection.
- If User Is Not Logged On:
1. Hold Power On/Off button (1) down for five seconds to
display the user name/password prompt.
2. Press the Enter button (12) to display the on-screen keyboard.
3. Input the user name.
4. Press the Enter button (12) to accept input and dismiss the
on-screen keyboard.
5. Use the Down Arrow button (12) to move to the “Password”
field.
6. Input password (use on-screen keyboard or numeric buttons
(3) for numbers).
7. Press the Enter button (12) to accept input and dismiss the
on-screen keyboard.
8. Press the OK button on the screen to accept input and display
the Yes/No” verification prompt (use Up/Down Arrow buttons
(12) to move between fields)
9. Press Enter button (12) to accept selection.

HIKVISION DS-7608NI-Q2/8P Specifications

General

DHCP client	Yes
Input bandwidth	80 Mbit/s
Maximum frame rate	60 fps
Maximum resolution	3840 x 2160 pixels
Alarm input channels	1
Video input channels	8 channels
Supported resolutions	1024 x 768, 1280 × 720, 1280 × 1024, 1920 × 1080, 1600 × 1200, 3840 × 2160
Video recording modes	720p, 1080p
Wi-Fi	No
HDD capacity	2000 GB
HDD interface	Serial ATA
Maximum storage capacity	16 TB
Number of HDDs supported	2
Networking standards	IEEE 802.3af, IEEE 802.3at
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN (RJ-45) ports	9
Supported network protocols	TCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP, HTTPS
Power over Ethernet (PoE) ports quantity	8
Product color	Black
Rack capacity	1U
LED indicators	LAN, Power, Status
AC input voltage	100 - 240 V
Power consumption (typical)	15 W
Total Power over Ethernet (PoE) budget	80 W
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	315 mm
Width	385 mm
Height	52 mm
Weight	3000 g
