Network Video Recorder User Manual
168
3) Select the font size to small, medium or large.
4) Set the overlay time of the characters. The value ranges 5 -3600 sec.
5) Set the delay time of POS event. The value ranges 5 -3600 sec. When the device has not
received the POS message over the defined delay time, the transaction is finished.
6) (optional) Check the checkbox to enable the POS Overlay in Live View. When this
feature is enabled, the POS information can be overlain on the live view image.
7) Select the font color for the characters.
Figure 9-11 Overlay Character Settings
You can adjust the size and position of textbox on the preview screen of POS settings interface by
dragging the frame.
Step 7 Click Apply to activate the settings.
Step 8 (Optional) You can click the Copy button to copy the current settings to other POS (s).
Figure 9-12 Copy POS Settings
