Quick Operation Guide of Digital Video Recorder
8
the device ID# is 255, the indicator is off when the device is controlled
by an IR remote).
Indicator turns red when controlled by a keyboard and purple when IR
remote and keyboard is used at the same time.
HDD indicator blinks red when data is being read from or written to
HDD.
MODEM (Not supported
by 9100/9000HFI-XT)
Reserved for future usage.
TX/RX indictor blinks blue when network connection is functioning
properly.
Guard indicator turns blue when the device is in armed status; at this
time, an alarm is enabled when an event is detected.
The indicator turns off when the device is unarmed. The arm/disarm
status can be changed by pressing and holding on the ESC button for
more than 3 seconds in live view mode.
Front Panel Lock
(for DS-9100/9000 series)
You can lock or unlock the panel by the key.
Slot for DVD-R/W. (Optional for DS-9100/9000HFI-RT)
Switch to the corresponding channel in Live view or PTZ Control mode.
Input numbers and characters in Edit mode.
Switch channels in All-day Playback mode.
The light of the button is blue when the corresponding channel is
recording; it is red when the channel is in network transmission status; it
is pink when the channel is recording and transmitting.
Universal Serial Bus (USB) ports for additional devices such as USB
mouse and USB Hard Disk Drive (HDD).
Back to the previous menu.
Press for arming/disarming the device in Live View mode.
Enter the Manual Record setting menu.
In PTZ control settings, press the button and then you can call a PTZ
preset by pressing Numeric button.
It is also used to turn audio on/off in the Playback mode.
The button is used to enter the Playback mode.
It is also used to auto scan in the PTZ Control menu.
Zoom in the PTZ camera in the PTZ Control setting.
Adjust focus in the PTZ Control menu.
It is also used to switch input methods (upper and lowercase alphabet,
symbols and numeric input).
Edit text fields. When editing text fields, it will also function as a
Backspace button to delete the character in front of the cursor.
On checkbox fields, pressing the button will tick the checkbox.
In PTZ Control mode, the button adjusts the iris of the camera.
In Playback mode, it can be used to generate video clips for backup.
Enter/exit the folder of USB device and eSATA HDD.
Switch main and spot output.
In PTZ Control mode, it can be used to zoom out the image.
