Table 2 Specifications for DS-9000HFI-ST
Model
DS-9004HFI-ST
DS-9008HFI-ST
DS-9016HFI-ST
Video/Audio
input
Video
compression
H.264
Analog video
input
4-ch
8-ch
16-ch
BNC (1.0 Vp-p, 75 Ω),
PAL / NTSC self-adaptive
IP video input
8-ch
16-ch
32-ch
Composite
video input
Up to 8-ch
(Analog video + IP
video)
Up to 16-ch (Analog
video + IP video )
Up to 32-ch (Analog
video + IP video )
Audio
compression
OggVorbis
Audio input
4-ch,
RCA (2.0 Vp-p, 1
KΩ)
8-ch,
Audio 1-4:
RCA (2.0 Vp-p, 1
KΩ)
Audio 5-8: DB26
connector
16-ch,
Audio 1-4:
RCA (2.0 Vp-p, 1 KΩ)
Audio 5-16: DB26
connector
Two-way audio
1-ch, RCA (2.0 Vp-p, 1 KΩ)
Video/Audio
output
HDMI output
1920 × 1080 / 60 Hz (1080P), 1920 × 1080 / 50 Hz (1080P), 1600 ×
1200 / 60 Hz, 1280 × 1024 / 60 Hz, 1280 × 720 / 60 Hz, 1024 × 768 / 60
Hz
VGA output
1920 × 1080 / 60 Hz (1080P), 1600 × 1200 / 60 Hz,1280 × 1024 / 60 Hz,
1280 × 720 / 60 Hz, 1024 × 768 / 60 Hz
CVBS output
2-ch (1 Main output +
1 Spot output)
5-ch (1 Main output
+ 4 Spot outputs)
5-ch (1 Main output +
4 Spot outputs)
BNC (1.0 Vp-p, 75 Ω),
resolution: PAL: 704 × 576, NTSC: 704 × 480
Video loop out
4-ch
8-ch
16-ch
BNC (1.0 Vp-p, 75 Ω)
Encoding
resolution
Main stream: 4CIF / 2CIF / CIF / QCIF
Sub-stream: CIF / QCIF
Frame rate
Main stream: 25 fps (P) / 30 fps (N)
Sub-stream: 25 fps (P) / 30 fps (N)
Video bitrate
32 Kbps ~ 8 Mbps
Audio output
2-ch, RCA (2.0 Vp-p, 1 KΩ)
Audio bitrate
16 Kbps
