Table 15 Specifications for DS-7600HI-ST
Model
DS-7604HI-ST
DS-7608HI-ST
DS-7616HI-ST
Video/Audio
input
Video
compression
H.264
Analog video
input
4-ch
8-ch
16-ch
BNC (1.0 Vp-p, 75 Ω),
PAL / NTSC self-adaptive
IP video input
8-ch
16-ch
32-ch
Composite
video input
Up to 8-ch (Analog
video + IP video)
Up to 16-ch (Analog
video + IP video )
Up to 32-ch (Analog
video + IP video )
Audio
compression
G.711
OggVorbis
Audio input
4-ch
RCA (2.0 Vp-p, 1 KΩ)
Two-way audio
1-ch, RCA (2.0 Vp-p, 1 KΩ) (Using audio input)
Video/Audio
output
HDMI / VGA
output
1920 × 1080 / 60 Hz (1080P), 1600 × 1200 / 60 Hz, 1280 × 1024 / 60
Hz, 1280 × 720 / 60 Hz, 1024 × 768 / 60 Hz
CVBS output
1-ch, BNC (1.0 Vp-p, 75 Ω),
resolution: PAL: 704 × 576, NTSC: 704 × 480
Video loop out
Optional
Encoding
resolution
Main stream: 4CIF / 2CIF / CIF / QCIF
Sub-stream: CIF / QCIF
Frame rate
Main stream: 25 fps (P) / 30 fps (N)
Sub-stream: 25 fps (P) / 30 fps (N)
Video bitrate
32 Kbps ~ 3 Mbps
Audio output
1-ch, RCA (Linear, 1 KΩ)
Audio bitrate
64 Kbps
Dual-stream
Support
Stream type
Video, Video & Audio
Playback
resolution
5 Megapixels /3 Megapixels / 1080P / UXGA / 720P / 4CIF / VGA /
DCF / 2CIF / CIF / QCIF
Synchronous
playback
8-ch
16-ch
16-ch
Hard disk
SATA
1 SATA interface
2 SATA interfaces
eSATA
Reserved
Capacity
Up to 4 TB capacity for each disk
External
interface
Network
interface
1; 10M / 100M
self-adaptive Ethernet
interface
1; 10M / 100M / 1000M self-adaptive Ethernet
interface
