HIKVISION DS-9104HFI-ST series User Manual

Quick Operation Guide of Digital Video Recorder
21
Table 3 Specifications for DS-8100HFI-ST
Model
DS-8104HFI-ST
DS-8108HFI-ST
DS-8116HFI-ST
Video/Audio
input
Video
compression
H.264
Analog video
input
4-ch
8-ch
16-ch
BNC (1.0 Vp-p, 75 Ω),
PAL / NTSC self-adaptive
Audio
compression
OggVorbis
Audio input
4-ch
8-ch
16-ch
BNC (2.0 Vp-p, 1 KΩ)
Two-way audio
1-ch, BNC (2.0 Vp-p, 1 KΩ)
Video/Audio
output
HDMI output
1920 × 1080 / 60 Hz (1080P), 1920 × 1080 / 50 Hz (1080P),1600 × 1200
/ 60 Hz, 1280 × 1024 / 60 Hz, 1280 × 720 / 60 Hz, 1024 × 768 / 60 Hz
VGA output
1920 × 1080 / 60 Hz (1080P), 1600 × 1200 / 60 Hz, 1280 × 1024 / 60
Hz, 1280 × 720 / 60 Hz, 1024 × 768 / 60 Hz
CVBS output
2-ch (1 Main output + 1 Spot output )
BNC (1.0 Vp-p, 75 Ω),
resolution: PAL: 704 × 576, NTSC: 704 × 480
Video loop out
Optional
Encoding
resolution
Main stream: 4CIF / 2CIF / CIF / QCIF
Sub-stream: CIF / QCIF
Frame rate
Main stream: 25 fps (P) / 30 fps (N)
Sub-stream: 25 fps (P) / 30 fps (N)
Video bitrate
32 Kbps ~ 8 Mbps
Audio output
2-ch, BNC (Linear, 600 Ω)
Audio bitrate
16 Kbps
Dual-stream
Support
Stream type
Video, Video & Audio
Playback
resolution
4CIF / 2CIF / CIF / QCIF
Synchronous
playback
4-ch
8-ch
16-ch
Hard disk
SATA
8 SATA interfaces for 4 HDDs + 1 DVD-R/W (default), or 8HDDs
eSATA
1 eSATA interface
Capacity
Up to 4 TB capacity for each disk
External
interface
Network
interface
2; 10M / 100M / 1000M self-adaptive Ethernet interface

HIKVISION DS-9104HFI-ST series Specifications

General

Brand	HIKVISION
Model	DS-9104HFI-ST series
Category	DVR
Language	English
