Table 9 Specifications for DS-9100HWI-ST
Model
DS-9104HWI-ST
DS-9108HWI-ST
DS-9116HWI-ST
Video/Audio
input
Video
compression
H.264
Analog video
input
4-ch
8-ch
16-ch
BNC(1.0Vp-p, 75Ω)
PAL/NTSC self-adaptive
Audio
compression
OggVorbis
Audio input
4-ch,
RCA (2.0 Vp-p, 1
KΩ)
8-ch,
Audio 1-4: RCA (2.0
Vp-p, 1 KΩ)
Audio 5-8: DB26
connector
16-ch,
Audio 1-4: RCA (2.0
Vp-p, 1 KΩ)
Audio 5-16: DB26
connector
Two-way audio
1-ch, RCA (2.0 Vp-p, 1 KΩ)
Video/Audio
output
HDMI / VGA
output
1920 × 1080 / 60 Hz (1080P), 1600 × 1200 / 60 Hz, 1280 × 1024 / 60
Hz, 1280 × 720 / 60 Hz, 1024 × 768 / 60 Hz
CVBS output
2-ch (1 Main output +
1 Spot output)
5-ch (1 Main output +
4 Spot outputs)
5-ch (1 Main output
+ 4 Spot outputs)
BNC (1.0 Vp-p, 75 Ω),
resolution: PAL: 704×576, NTSC: 704×480
Video loop out
4-ch
8-ch
16-ch
BNC (1.0 Vp-p, 75 Ω)
Encoding
resolution
Main stream: WD1 / 4CIF / 2CIF / CIF / QCIF
Sub-stream: CIF / QCIF
Frame rate
Main stream: 25 fps (P) / 30 fps (N)
Sub-stream: 25 fps (P) / 30 fps (N)
Video bitrate
32 Kbps ~ 8 Mbps
Audio output
2-ch, RCA (2.0 Vp-p, 1 KΩ)
Audio bitrate
16 Kbps
Dual-stream
Support
Stream type
Video, Video & Audio
Playback
resolution
WD1 / 4CIF / 2CIF / CIF / QCIF
Synchronous
playback
4-ch
8-ch
16-ch
Hard disk
SATA
8 SATA interfaces for 4 HDDs + 1 DVD-R/W (default), or 8HDDs
eSATA
1 eSATA interface
Capacity
Up to 4TB capacity for each disk
External
Network
2; 10M/100M/1000M self-adaptive Ethernet interface
