Table 12 Specifications for DS-8000HWI-ST
Model
DS-8004HWI-ST
DS-8008HWI-ST
DS-8016HWI-ST
Video/Audio
input
Video
compression
H.264
Analog video
input
4-ch
8-ch
16-ch
BNC (1.0 Vp-p, 75 Ω),
PAL /NTSC self-adaptive
IP video input
8-ch
16-ch
32-ch
Composite
video input
Up to 8-ch (Analog
video + IP video)
Up to 16-ch (Analog
video + IP video )
Up to 32-ch (Analog
video + IP video )
Audio
compression
OggVorbis
Audio input
4-ch
8-ch
16-ch
BNC (2.0 Vp-p, 1 KΩ)
Two-way audio
1-ch, BNC (2.0 Vp-p, 1 KΩ)
Video/Audio
output
HDMI / VGA
output
1920 × 1080 / 60 Hz (1080P), 1600 × 1200 / 60 Hz, 1280 × 1024 / 60 Hz,
1280 × 720 / 60 Hz, 1024 × 768 / 60 Hz
CVBS output
2-ch (1 Main output + 1 Spot output)
BNC (1.0 Vp-p, 75 Ω),
resolution: PAL: 704 × 576, NTSC: 704 × 480
Video loop out
Optional
Encoding
resolution
Main stream: WD1 / 4CIF / 2CIF / CIF / QCIF
Sub-stream: CIF / QCIF
Frame rate
Main stream: 25 fps (P) / 30 fps (N)
Sub-stream: 25 fps (P) / 30 fps (N)
Video bitrate
32 Kbps ~ 8 Mbps
Audio output
2-ch, BNC (Linear, 600 Ω)
Audio bitrate
16 Kbps
Dual-stream
Support
Stream type
Video, Video & Audio
Playback
resolution
5 Megapixels /3 Megapixels / 1080P / UXGA / 720P / WD1/ 4CIF /
VGA / DCF / 2CIF / CIF / QCIF
Synchronous
playback
8-ch
16-ch
16-ch
Hard disk
SATA
8 SATA interfaces for 4 HDDs + 1 DVD-R/W (default), or 8HDDs
eSATA
1 eSATA interface
Capacity
Up to 4TB capacity for each disk
External interface
Network interface
2; 10M /100M /1000M self-adaptive Ethernet interface
Serial interface
RS-232; RS-485; Keyboard
