HIKVISION DS-9104HFI-ST series

Quick Operation Guide of Digital Video Recorder
24
Synchronous
playback
8-ch
16-ch
16-ch
Hard disk
SATA
8 SATA interfaces for 4 HDDs + 1 DVD-R/W (default), or 8HDDs
eSATA
1 eSATA interface
Capacity
Up to 4 TB capacity for each disk
External
interface
Network
interface
2; 10M / 100M / 1000M self-adapter Ethernet interface
Serial interface
RS-232, RS-485, Keyboard
USB port
2 × USB2.0
Alarm in / out
4 / 2
16 / 4
16 / 4
General
Power supply
100 ~ 240 VAC, 6.3 A, 50 ~ 60 Hz
Consumption
(without hard
disk or
DVD-R/W)
Max. 35 W
Max. 40 W
Max. 45 W
Working
temperature
-10 ºC ~ +55 ºC (14 ºF ~ 131 ºF)
Working
humidity
10% ~ 90%
Chassis
19-inch rack-mounted 2U chassis
Dimensions
(W × D × H)
445 × 470 × 90 mm (17.5 × 18.5 × 3.5 in)
Weight
Approx. 8 kg / 17.6 lb (without hard disk or DVD-R/W)
