Network Video Recorder User Manual
138
Click Apply.
Region Exiting Detection
Purpose
The region exiting detection function detects objects that exit from a pre-defined virtual region.
Go to System > Event > Smart Event.
Click Region Exiting.
Region Exiting Detection
Select a camera to configure.
Check Enable Region Exiting Detection.
Optionally, check Save VCA Picture to save the captured region exiting detection pictures.
Follow these steps to set the detection rules and detection areas.
Select Arming Region. Up to 4 regions are selectable.
Set Sensitivity.
Sensitivity: The higher the value is, the more easily the detection alarm will be triggered.
Its range is [0-100].
Click Draw Region and draw a quadrilateral in the preview window by specifying four vertices
of the detection region.
Set the arming schedule. Refer to Chapter 11.1 Configure Arming Schedule.
