HIKVISION DS-9600NI-I8 Series User Manual

Network Video Recorder User Manual
37
Panel Description
No.
Name
Description
1
LAN Interface
1 network interface provided for DS-7700NI-
I4/P, and 2 network interfaces for DS-7700NI-I4.
2
AUDIO OUT
RCA connector for audio output.
3
LINE IN
RCA connector for audio input.
4
HDMI
HDMI video output connector.
5
USB 3.0 interface
Universal Serial Bus (USB) ports for additional
devices such as USB mouse and USB Hard Disk
Drive (HDD).
6
RS-232 Interface
Connector for RS-232 devices.
7
VGA
DB9 connector for VGA output. Display local
video output and menu.
8
RS-485 Interface
Half-duplex connector for RS-485 devices.
9
ALARM IN
Connector for alarm input.
ALARM OUT
Connector for alarm output.
10
GROUND
Ground (needs to be connected when device
starts up).
11
Power Supply
100 to 240 VAC power supply.
12
Power Switch
Switch for turning on/off the device.
13
Network Interfaces
with PoE function (for
DS-7700NI-I4/P)
Network interfaces for the cameras and to
provide power over Ethernet.
14
eSATA
Connects external SATA HDD, CD/DVD-RW.
15
VIDEO OUT
BNC connector for video output.
16
ALARM OUT (Optional)
Connector for alarm output.
