Table 3-1 Terminal Description
Line
Group
No.
Function
Color
Termina
l Name
Description
Line
Group
A
A1
Power
Input
Red
+12V
12V DC Power
Supply
A2
Black
GND
GND
Line
Group
B
B1
Alarm
Input
Yellow/Blue
IN1
Alarm Input 1
B2
Yellow/Black
GND
GND
B3
Yellow/Orange
IN2
Alarm Input 2
B4
Alarm
Output
Yellow/Purple
NC
Alarm Output
Wiring
B5
Yellow/Brown
COM
B6
Yellow/Red
NO
Line
Group
C
C1
RS485
Commun
ication
Port
Yellow
485 +
RS485 Wiring
C2
Blue
485 -
C3
Wiegand
Output
Green
W0
Wiegand Wiring 0
C4
White
W1
Wiegand Wiring 1
