Access Control Terminal·Quick Start Guide
36
3. Modify parameters of the serial port, including working mode, Baud Rate, and
RS485 address.
Working Mode: Up serial port and down serial port are supported.
Set the working mode of the serial port as Down (downstream) if the access
control terminal is connected to the external card reader.
Baud Rate: The current suppoted Baud Rate is 19200.
RS485 Address: When the access control terminal works as a RS485 card reader, the
default RS485 address is 1.
Click the key to enter and exit the editing mode.
Click the Right/Left direction keys to choose contents.
Click the # key to switch the mode between “Yes” mode and “No” mode.
4. Move the cursor to the OK button, and click the # key.
6.2.3 Wiegand Settings
Purpose:
When the access control terminal works as the Wiegand card reader, you should set
Wiegand parameters.
Steps:
1. Move the cursor to Wiegand (Wiegand settings) by using direction keys on the
communication settings interface.
2. Click the # key to enter the Wiegand settings interface.
Figure 6-16 Wiegand Settings Interface
3. Edit parameters of the serial port, including enabling the Wiegand, and the
Wiegand mode.
