HIKVISION DS-K1T501SF User Manual

Video Access Control Terminal·User Manual
113
The following buttons are available on the local playback page:
CIF/4CIF
Display the video in cif/4cif resolution.
Full Screen
Display the local playback page in full screen mode.
Close
Close the local playback page of the video files.
Pause/Play
Pause/Start the playback of the video files.
Stop
Stop the playback of the video files.
Speed
Set the playback speed.
Single Frame
Play back the video files frame by frame.
Digital Zoom
Enable the digital zoom function. Click again to
disable.
Enable/Disable
Audio
Click to enable/disable the audio in the local
playback.
Capture
Capture the picture in the playback process.
Capturing Picture in Live View
Steps:
1. Move the mouse pointer to the display window in live view to show the toolbar.
2. Click the icon in the toolbar of the display window or on the right-click Live View
Management Menu.
A small window of the captured picture will be displayed to notify whether the capturing
operation is done or not.
Note: The saving path of the captured pictures can be set on the System Configuration interface.
For details, see User Manual of iVMS-4200 Client Software.
Viewing Captured Pictures
The pictures captured in live view are stored in the PC running the software. You can view the
captured pictures if needed.
Steps:
1. Click File->Open Image File to open the Captured Images page.

HIKVISION DS-K1T501SF Specifications

General

Type	Basic access control reader
Product color	Gray
Cards capacity	50000 cards
Housing material	Metal
Keypad integrated	No
Fingerprint reader	Yes
Authentication type	Access chip/card, Biometric, Face recognition
Transaction capacity	200000
Fingerprint sensor type	Optical
Identification (1:N) time	1.5 s
False Rejection Rate (FRR)	0.01 %
False Acceptance Rate (FAR)	0.001 %
Access chip/card reader type	Contactless
International Protection (IP) code	IP65
DC current (max)	600 A
DC voltage range	12 V
Total megapixels	2 MP
Front camera type	Single camera
PC connected	-
RS-485 ports	1
Operating temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	218 mm
Width	78 mm
Height	41 mm
