Stop Bit
The stop bit when the devices are communicang via the RS-485 protocol.
Parity/Flow Ctrl/Communicaon Mode
Enabled by default.
Set Wiegand Parameters
You can set the Wiegand transmission direcon.
Steps
1.
Tap Conguraon → Access Control → Wiegand Sengs .
Figure 8-15 Wiegand Page
2.
Enable Wiegand to enable the Wiegand funcon.
3.
Set a transmission direcon.
Input
The device can connect a Wiegand card reader.
Output
The can connect an external access controller. And the two devices will transmit the card No.
via Wiegand 26 or 34.
4.
Click Save to save the
sengs.
DS-K1T6QT-F43 Series Face Recognion Terminal User Manual
95
