HIKVISION DS-KIS603-P Configuration Guide

•
When the zone type is set to be Delay Alarm, only under arming mode, the
indoor staon will receive alarm message when the detector is triggered.
Under disarming mode, it will not receive alarm message when the detector
is triggered.
•
Aer seng enter delay me, if OK is pressed within the enter delay me
aer the alarm, the alarm event will not be uploaded to the management
center; if OK is not pressed within the enter delay me aer the alarm, the
alarm event will be uploaded to the management center.
•
The exit delay is the me between you enable the arming mode and the
arming takes eect.
IP Camera Informaon
You can add, delete and modify cameras that can be added to the video intercom
products, with two ways of geng stream: direct or URL. By exporng and imporng
the added device informaon, you can edit added devices parameters in batch.
Add Camera
Steps
1.
Click IP Camera Informaon to enter IP camera informaon page.
Figure 2-12 IP Camera Informaon
2.
Click Add to pop up the device adding dialog box.
3.
Enter corresponding
informaon (device name, IP address, port No., user name,
password, etc.), and click OK.
Note
Indoor extension does not support this funcon.
Export and Import Added Device Informaon
Network Indoor Staon Conguraon Guide
29

HIKVISION DS-KIS603-P Specifications

General

Model	DS-KIS603-P
Category	Intercom System
Resolution	1024 x 600
Camera	2 MP HD Camera
Audio Input	Built-in Omnidirectional Microphone
Audio Output	Built-in Loudspeaker
Operating Temperature	-10°C to 55°C (14°F to 131°F)
Supported Protocols	TCP/IP, SIP, RTSP
Display	7-inch TFT LCD
Network Protocol	TCP/IP
Power Supply	12 VDC
Installation	Surface Mount
IR Supplement	IR Supplement
Protection Level	IP65
Power Consumption	<10 W
Humidity	10% - 90% (non-condensing)
Communication Interface	Ethernet
