Panic Alarm Station User Manual
50
you need to enter the port number in the login page.
3. Go to NAT page, enable UPnP to open the device port.
4. Select Port Mapping Mode as Auto or Manual.
Auto
You do not need to set port mapping on the router. You can open the port only by enabling
UPnP.
Manual
When you select Manual and enable UPnP, you need to enter the external port number and
enable UPnP on the router to open the port. You do not need to change the port of the device
itself.
5. Click Save.
Device Access - SIP
After setting the SIP server, the device will be enrolled to the SIP server automatically. The devices
under the same SIP server address can communicate with each other.
Click Network → Device Access → SIP.
Private Protocol
Steps
1. Enable SIP.
Enrollment Status
Display the device enrollment status. If the device has been enrolled to the SIP server, it
displays Enrolled. Otherwise it displays Not Enrolled.
2. Select IPv4 or Domain.
3. Set parameters.
Device ID
The device ID can only be set as a number and no more than 6 digits. It is a unique identification
of the device, which facilitates the interaction between the panic alarm center station and
front-end device.
Device Location
You can enter the device location information with a maximum of 32 characters.
User Information
You can enter IP, Server Port, Enrollment Password, etc.
Local Port
The default local port is 5060.
Enrollment Period
The time interval between devices registering with the SIP server.
4. Click Save.
Standard SIP Protocol
