HIKVISION E Series Installation Manual

E Series IR Speed Dome Installation Manual
© Hikvision Digital Technology Co., Ltd. All Rights Reserved.
20
3.2 Corner Mounting Applications
Before you start:
The corner mounting is applicable to the indoor/outdoor 90° solid corner construction.
3.1.1 Components
 Wall Mount
Figure 3-5 Wall Mount
 Corner Adapter
A corner adapter has to be used together with a wall mount for corner mounting applications.
Figure 3-6 Corner Adapter
 Mounting Accessories
Figure 3-7 Hex Screws (M8×30), Nuts, Spring Washers and Flat Washers
