HIKVISION E Series Installation Manual

E Series IR Speed Dome Installation Manual
© Hikvision Digital Technology Co., Ltd. All Rights Reserved.
23
Figure 3-12 Pole Adapter
 Pole Mounting Hoops
Pole mounting hoop is used for pole mounting with pole adapter and wall mount. There are
following dimensions selectable: φ59-82mm, φ84-108mm, φ103-127mm, φ130-152mm,
φ155-178mm, φ180-203mm and φ194-216mm. Dimensions can be customized according to your
demand.
Note: The dimensions of the pole mounting hoop must match with the diameter of the pole
adapter.
Figure 3-13 Pole Mounting Hoops
 Mounting Accessories
