HIKVISION HWD Series User Manual

Digital Video Recorder User Manual
116
Step 6 Click Linkage Action tab to set up alarm response actions of motion alarm (please refer to
Chapter 8.8 Setting Alarm Response Actions).
Repeat the above steps to set up arming schedule of other days of a week.
Click the OK button to complete the motion detection settings of the channel.
Step 7 If you want to set motion detection for another channel, repeat the above steps or just copy
the above settings to it.
You are not allowed to copy the “Trigger Channel” action.

HIKVISION HWD Series Specifications

General

Operating System	Embedded Linux
Video Compression	H.264, H.265
Video Input	4/8/16 channels
Video Output	1 HDMI, 1 VGA
Audio Output	1 channel
Network Interface	1 RJ45 10M/100M Self-Adaptive Ethernet Interface
USB Interface	2 USB 2.0
HDD Interface	SATA
Power Supply	12 VDC
Mobile Access	Hik-Connect
Encoding Resolution	1080p, 720p, VGA, WD1, 4CIF, CIF
