HIKVISION HWN-2104H-4P User Manual

Network Video Recorder User Manual
157
Behavior Search
Purpose:
The behavior analysis detects a series of suspicious behavior based on VCA detection, and certain
linkage methods will be enabled if the alarm is triggered.
Enter the Behavior Search interface.
Menu>VCA Search> Behavior Search
Select the camera (s) for the behavior search.
Specify the start time and end time for searching the matched pictures.
Behavior Search Interface
Select the VCA detection type from the dropdown list, including the line crossing detection,
intrusion detection, unattended baggage detection, object removal detection, region
entrance detection, region exiting detection, parking detection, loitering detection, people
gathering detection and fast moving detection.
Click Search to start searching. The search results of pictures are displayed in list or in chart.

HIKVISION HWN-2104H-4P Specifications

General

Input bandwidth	40 Mbit/s
Output bandwidth	60 Mbit/s
Maximum resolution	1920 x 1080 pixels
Video input channels	4 channels
Supported resolutions	1920x1080, 1280x1024, 1280x720, 1024x768
Video formats supported	H.264, H.264+, H.265, H.265+
Wi-Fi	No
HDD capacity	0 GB
HDD interface	Serial ATA
Maximum storage capacity	6 TB
Number of HDDs installed	0
Number of HDDs supported	1
Networking standards	IEEE 802.3af, IEEE 802.3at
USB 2.0 ports quantity	2
Ethernet LAN data rates	10, 100 Mbit/s
Power over Ethernet (PoE)	Yes
Ethernet LAN (RJ-45) ports	5
Supported network protocols	TCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, UPnP
Output voltage	48 V
Product color	White
Rack capacity	1U
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	205 mm
Width	200 mm
Height	48 mm
Weight	1000 g
