Network Video Recorder User Manual
171
3) Click Apply button to save the settings.
4) You can click Refresh button to get the latest status of the port mapping.
UPnPSettings Finished-Manual
Enter the virtual server setting page of router; fill in the blank of Internal Source Port with
the internal port value, the blank of External Source Port with the external port value, and
other required contents.
Each item should be corresponding with the device port, including server port, http port, RTSP port
and https port.
Setting Virtual Server Item
The above virtual server setting interface is for reference only, it may be different due to different
router manufactures. Please contact the manufacture of router if you have any problems with
setting virtual server.
Configuring Virtual Host
Purpose:
You can directly get access to the IP camera management interface after enabling this function.
The Virtual host function can be only configured through the web browser.
Enter the Advanced settings interface, as shown in the Figure 11-21.
Configuration > Network > Advanced Settings > Other

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HIKVISION HWN-2104H-4P and is the answer not in the manual?

HIKVISION HWN-2104H-4P Specifications

General IconGeneral
Input bandwidth40 Mbit/s
Output bandwidth60 Mbit/s
Maximum resolution1920 x 1080 pixels
Video input channels4 channels
Supported resolutions1920x1080, 1280x1024, 1280x720, 1024x768
Video formats supportedH.264, H.264+, H.265, H.265+
Wi-FiNo
HDD capacity0 GB
HDD interfaceSerial ATA
Maximum storage capacity6 TB
Number of HDDs installed0
Number of HDDs supported1
Networking standardsIEEE 802.3af, IEEE 802.3at
USB 2.0 ports quantity2
Ethernet LAN data rates10, 100 Mbit/s
Power over Ethernet (PoE)Yes
Ethernet LAN (RJ-45) ports5
Supported network protocolsTCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, UPnP
Output voltage48 V
Product colorWhite
Rack capacity1U
Operating temperature (T-T)-10 - 55 °C
Operating relative humidity (H-H)10 - 90 %
Weight and Dimensions IconWeight and Dimensions
Depth205 mm
Width200 mm
Height48 mm
Weight1000 g
