Network Video Recorder User Manual
174
Configuring Network Detection
Purpose:
You can obtain network connecting status of NVR through the network detection function,
including network delay, packet loss, etc.
Testing Network Delay and Packet Loss
Enter the Network Traffic interface.
Menu >Maintenance>Net Detect
Click the Network Detection tab to enter the Network Detection menu, as shown in Figure
11-24.
Network Detection Interface
Enter the destination address in the text field of Destination Address.
Click Test button to start testing network delay and packet loss. The testing result pops up
on the window. If the testing is failed, the error message box will pop up as well. Refer to
Figure 11-25.
Testing Result of Network Delay and Packet Loss
Exporting Network Packet
Purpose:
By connecting the NVR to network, the captured network data packet can be exported to USB-flash
disk, SATA/eSATA, DVD-R/W and other local backup devices.
Enter the Network Traffic interface.
Menu >Maintenance>Net Detect
Click the Network Detection tab to enter the Network Detection interface.
Select the backup device from the dropdown list of Device Name, as shown in Figure 11-26.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HIKVISION HWN-2104H-4P and is the answer not in the manual?

HIKVISION HWN-2104H-4P Specifications

General IconGeneral
Input bandwidth40 Mbit/s
Output bandwidth60 Mbit/s
Maximum resolution1920 x 1080 pixels
Video input channels4 channels
Supported resolutions1920x1080, 1280x1024, 1280x720, 1024x768
Video formats supportedH.264, H.264+, H.265, H.265+
Wi-FiNo
HDD capacity0 GB
HDD interfaceSerial ATA
Maximum storage capacity6 TB
Number of HDDs installed0
Number of HDDs supported1
Networking standardsIEEE 802.3af, IEEE 802.3at
USB 2.0 ports quantity2
Ethernet LAN data rates10, 100 Mbit/s
Power over Ethernet (PoE)Yes
Ethernet LAN (RJ-45) ports5
Supported network protocolsTCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, UPnP
Output voltage48 V
Product colorWhite
Rack capacity1U
Operating temperature (T-T)-10 - 55 °C
Operating relative humidity (H-H)10 - 90 %
Weight and Dimensions IconWeight and Dimensions
Depth205 mm
Width200 mm
Height48 mm
Weight1000 g
