Network Video Recorder User Manual
167
3) Click OK to save the settings.
OPTION 2: Create the authorized certificate
1) Click the Create button to create the certificate request.
2) Download the certificate request and submit it to the trusted certificate authority for
signature.
3) After receiving the signed valid certificate, import the certificate to the device.
There will be the certificate information after you successfully create and install the
certificate.
Installed Certificate Property
Check the checkbox to enable the HTTPS function.
Click the Save button to save the settings.
Configuring Email
Purpose:
The system can be configured to send an Email notification to all designated users if an alarm
event is detected, etc., an alarm or motion event is detected or the administrator password is
changed.
Before configuring the Email settings, the NVR must be connected to a local area network (LAN)
that maintains an SMTP mail server. The network must also be connected to either an intranet or
the Internet depending on the location of the e-mail accounts to which you want to send
notification.
Enter the Network Settings interface.
Menu >Configuration> Network
Set the IPv4 Address, IPv4 Subnet Mask, IPv4 Gateway and the Preferred DNS Server in the
Network Settings menu, as shown in Figure 11-14.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HIKVISION HWN-2104H-4P and is the answer not in the manual?

HIKVISION HWN-2104H-4P Specifications

General IconGeneral
Input bandwidth40 Mbit/s
Output bandwidth60 Mbit/s
Maximum resolution1920 x 1080 pixels
Video input channels4 channels
Supported resolutions1920x1080, 1280x1024, 1280x720, 1024x768
Video formats supportedH.264, H.264+, H.265, H.265+
Wi-FiNo
HDD capacity0 GB
HDD interfaceSerial ATA
Maximum storage capacity6 TB
Number of HDDs installed0
Number of HDDs supported1
Networking standardsIEEE 802.3af, IEEE 802.3at
USB 2.0 ports quantity2
Ethernet LAN data rates10, 100 Mbit/s
Power over Ethernet (PoE)Yes
Ethernet LAN (RJ-45) ports5
Supported network protocolsTCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, UPnP
Output voltage48 V
Product colorWhite
Rack capacity1U
Operating temperature (T-T)-10 - 55 °C
Operating relative humidity (H-H)10 - 90 %
Weight and Dimensions IconWeight and Dimensions
Depth205 mm
Width200 mm
Height48 mm
Weight1000 g
