HIKVISION K1108AMK Series - Wiring Cables; Description of Cable

No. Descripon DIP Switch Status
Note
• For EM card reader, the DIP
switch is reserved.
• For Desre card reader, the
DIP switch is for reading
card No.
recognion funcon, disable
door open via NFC card.
6 Wiegand protocol or RS-485
protocol.
1: Wiegand protocol
0: RS-485 protocol
7 Wiegand Protocol (available
when No. 6 is 1)
1: Wiegand protocol of 26-bit;
0: Wiegand protocol of 34-bit.
8 Matched Resistance (available
for RS-485 protocol)
1: Enable
0: Disable
3.3 Wiring Cables
Wire the cables between controller and card reader, thus to establish the communicaon between
them.
3.3.1
Descripon of Cable
The descripon of 10 cables is shown below.
Table 3-2
Descripon of Cable
Color Descripon
Orange Wiegand ERR (Available for Wiegand Protocol)
Brown Wiegand OK (Available for Wiegand Protocol)
White Wiegand W1 (Available for Wiegand Protocol)
Green Wiegand W0 (Available for Wiegand Protocol)
Blue RS-485-
Yellow RS-485+
Red PWR (+12 VDC)
Black GND
