Chapter 3 Installaon
3.1 Installing PSAM Card
Note
PSAM card slot is only available for CPU card reader. Insert the PSAM card into the slot according to
the direcon shown below.
Figure 3-1 PSAM Card Slot
3.2 DIP Switch Descripon
The DIP switch module is shown below. The No. of DIP switch from le to right is 1 to 8.
When the switch is towards ON, it means the switch is enabled, otherwise, the switch is o. If you
set the DIP switch like the
gure displayed below, its binary value is 00001100, and its decimal
value is 12.
Table 3-1
Descripon of DIP Switch
No. Descripon DIP Switch Status
1 to 4 Address of RS-485 1: 1
0: 0
5 Card Security 1: Disable M1 card encrypon
funcon, disable non-M1 card
recognion funcon, enable
door open via NFC card, read
card No.
0: Enable M1 card
encrypon
funcon, enable non-M1 card
