4.17 Knee Section Motor
Chapter 4: Removal, Replacement, and Adjustment Procedures
4.17 Knee Section Motor
Tools required: T25 Torx®
1
screwdriver
Wire cutters
13 mm wrench
Jack stands
Removal
1. Set the brakes.
2. Raise the bed to the high position.
3. Raise the head section to the highest position.
4. Place the jack stands under the knee section.
5. Carefully lower the bed onto the jack stands to relieve pressure on the knee
motor.
SHOCK HAZARD:
Unplug the bed from its power source. Failure to do so could result in
personal injury or equipment damage.
6. Unplug the bed from its power source.
7. Remove the screws (A) securing the cover (B) to the bed (C) (see figure 4-
29 on page 4-58).
8. Remove the cover (B).
9. Remove the two screws (D) securing the electronics module cover (E) to
the electronics module (F).
10. Remove the electronics module cover (E).
11. Disconnect the knee section motor from the motor control P.C. board
inside the electronics module (F).
12. Cut and remove any cable ties securing the motor cable (G) to the bed
frame (H)
(see figure 4-30 on page 4-59).
13. Remove the rue ring (J) from the pin (K) at the foot end of the motor (L).
1. Torx® is a registered trademark of Textron, Inc.
4
VersaCare™ Bed Service Manual (MAN333 REV 2) Page 4 - 57
