Specifications
Chapter 1: Introduction
1
Specifications
For VersaCare™ Bed specifications, see table 1-1 on page 1-5.
Table 1-1. Specifications
Feature Dimension
Total Length:
Foot Section Extended 94.5" (240.0 cm)
Foot Section Retracted 82.5" (210.0 cm)
Maximum Width (siderails stored) 37" (94 cm)
Maximum Width (siderails up) 40" (102 cm)
Maximum Headboard Height 39.5" (100 cm)
Mattress to Siderail Height 9.5" (24 cm)
Minimum Under-Bed Clearance 3" (8 cm)
1.25" (3.18 cm) for IntelliDrive® Trans-
port System beds
Wheel Base 26.75" x 62" (67.95 cm x 157.48 cm)
Surface Dimensions:
Surface Width 35.5" (90 cm)
Surface Length 86.4" (219.5 cm)
Surface Mattress Thickness 8" (20 cm) (measured in the center of the
mattress)
Surface Weight 25 lb (11 kg) for treatment, 26 lb (12 kg)
for short stay
Caster Size 5" (13 cm) standard,
or
6" (15 cm) optional (standard on IntelliD-
rive® Transport System beds)
Bed Lift Capacity (safe working load)
(includes patient weight, mattress, IV
poles, and such)
550 lb (249 kg)
Total Weight without Surface 495 lb (224 kg)
Head Section Inclination (maximum) 65°
Knee Section Inclination (maximum) 16°
Foot Section Inclination (maximum) -27°
VersaCare™ Bed Service Manual (MAN333 REV 2) Page 1 - 5
