Hill-Rom VersaCare P3200 Service Manual

4.37 Transport Handle—IntelliDrive® Transport System
Chapter 4: Removal, Replacement, and Adjustment Procedures
Replacement
1. Thread the transport handle cables (D) of the new transport handle (H)
through the bed (C).
2. Install the transport handle (H) on the bed (C).
3. Align the mounting hole in the transport handle (H) with the hole in the bed
(C).
4. Install the screw (G) and nut (F) through the bed (C) and transport handle
(H).
5. Stow the transport handle (H).
6. Route and connect the transport handle cables (D) to the interface P.C.
board (E):
• Connect the enable switch cable (two-pin) to connector P5 on the
interface P.C. board (E).
• Connect the strain gauge cable (five-pin) to connector P2 on the
interface P.C. board (E).
7. Using a common ground, make sure the voltage on the interface P.C. board
(E) at P6, pin 1, is between 2.49 V DC and 2.51 V DC. If necessary, adjust
R8.
8. Install the power supply cover (B) onto the bed (C) (see figure 4-61 on
page 4-117).
9. Install the six screws (A) to secure the power supply cover (B) to the bed
(C).
10. To make sure the VersaCare™ Bed operates correctly, do the “Function
Checks” on page 2-6.
4
VersaCare™ Bed Service Manual (MAN333 REV 2) Page 4 - 119

Hill-Rom VersaCare P3200 Specifications

General

Type	Hospital Bed
Trendelenburg Position	Yes
Reverse Trendelenburg Position	Yes
Side Rails	Yes, integrated
Power Source	Electric
Wheel Type	Locking casters
Height Adjustment	15" - 30"
Maximum Head Elevation	70 degrees
Maximum Knee Elevation	40 degrees
Height Adjustability	15" - 30"
Head and Foot Adjustment	Yes
Weight Capacity	500 lbs
