SERVICE LIGHT
The service light will be “lit” if the security system requires service. If the service light is “lit”,
press the [*] key followed by the [2] key to determine the service condition. One or more
zone lights will illuminate indicating what service(s) is required. Call your local security
installation company immediately for these problems. Below is a listing of what each light
means in a service condition.
Key Sequence Operation
1. Enter keys [*] [2] and use the table
below to identify the service condition
.
Condition
LIGHT
SYSTEM FAULT - Press the [1] key. The zone light(s) that is illuminated corresponds to
the system fault(s) below:
1 Over Current Fault
2 Siren Trouble
3 Box Tamper
4 Expander Power
5 Expander Low Battery
6 Expander Box Tamper
7 Expander Trouble
8 Reserved
1
Note: Faults 1 & 2 are global in nature and will affect all areas of a multi-area system.
Press the [#] key to return to the 1 of 8 service lights.
2 ZONE TAMPER - Press the [2] key and the zone light(s) will illuminate showing the
zone(s) that is tampered. Press the [#] key to return to the 1 of 8 service lights.
3 ZONE LOW BATTERY - Press the [3] key. The zone light(s) will illuminate showing
which zone(s) has a low battery. This only applies to wireless zones. Press the [#] key to
return to the 1 of 8 service lights.
4 ZONE LOSS OF SUPERVISION - Press the [4] key and the zone light(s) will illuminate
showing which zone(s) has loss of supervision. This only applies to wireless zones.
Press [#] key to return to the 1 of 8 service lights.
5 ZONE TROUBLE - Press the [5] key and the zone light(s) will illuminate showing which
zone(s) has a trouble condition. Press the [#] key to return to the 1 of 8 service lights.
6 TELEPHONE LINE TROUBLE/LINE CUT - There is telephone line trouble or the
telephone line has been cut. The service light will remain lit until the telephone trouble
clears and a user code is entered. Note: This fault is global in nature and will affect all
areas of a multi-area system.
7 FAILURE TO COMMUNICATE – There is a failure to communicate between your
system and the central station. Note: This fault is global in nature and will affect all areas
of a multi-area system.
8 LOSS OF SYSTEM TIME - There has been a loss of power and your system clock
needs to be reset. Instructions are on page 15. Note: This fault is global in nature and
will affect all areas of a multi-area system.
Exit To exit the Service Light Mode - press the [#] key.
V2.02
Page 20
