Switching other power tools, machines or appliances on and off can cause undervoltage and/or
overvoltage peaks, resulting in damage to the machine.
4 Technical data
4.1 Technical data
Weight (600 mm rail) in accordance with EPTA procedure 01
9.8 kg
Max. permissible water supply pressure
6 bar
Rated speed under no load, 1st gear
740 /min
Rated speed under no load, 2nd gear
1,580 /min
Dimensions of drill stand, short rail (L x W x H)
330 mm x 147 mm x 600 mm
Dimensions of drill stand, medium-length rail (L x W x H)
330 mm x 147 mm x 720 mm
Dimensions of drill stand, long rail (L x W x H)
330 mm x 147 mm x 830 mm
Protection class
Protection class I (earthed)
4.2 Gears and corresponding core bit diameters
* Your machine's core bit diameter is stated on the type identification plate.
Second gear can be used to achieve faster progress when drilling holes up to 82 mm (3 1⁄2 in) in
lightly reinforced concrete.
Gear Core bit diameter Idling speed
1 57 ... 132 (*162) mm 740 /min
2 16 ... 52 mm 1,580 /min
4.3 Noise information and vibration values in accordance with EN 62841
The sound pressure and vibration values given in these instructions were measured in accordance with a
standardized test and can be used to compare one power tool with another. They can also be used for a
preliminary assessment of exposure.
The data given represent the main applications of the power tool. However, if the power tool is used for
different applications, with different accessory tools, or is poorly maintained, the data can vary. This can
significantly increase exposure over the total working period.
An accurate estimation of exposure should also take into account the times when the tool is switched off, or
when it is running but not actually being used for a job. This can significantly reduce exposure over the total
working period.
Identify additional safety measures to protect the operator from the effects of noise and/or vibration, for
example: maintaining the power tool and accessory tools, keeping the hands warm, organization of work
patterns.
Noise information
Typical A-weighted sound power level
102 dB
Typical A-weighted emission sound pressure level
89 dB
Uncertainty for the given sound pressure level
3 dB
Vibration values
Drilling in concrete (wet), a
h
2.5 m/s²
Uncertainty (K)
1.5 m/s²
