for the type of dust generated. Ensure that the workplace is well ventilated. Follow national
requirements for the materials you want to work with.
Electrical safety
▶ Before beginning work, check the working area (e.g. using a metal detector) to ensure that no
concealed electric cables or gas and water pipes are present. External metal parts of the power tool
may become live, for example, when an electric cable is damaged accidentally. This presents a serious
risk of electric shock.
Careful handling and use of batteries
▶ Observe the special guidelines applicable to the transport, storage and use of lithium-ion batteries.
▶ Do not expose batteries to high temperatures and keep them away from fire. There is a risk of
explosion.
▶ Do not disassemble, crush or incinerate batteries and do not subject them to temperatures over
80°C (176°F). This presents a risk of fire, explosion or injury through contact with caustic substances.
▶ Never continue to use or attempt to charge damaged batteries, e.g. batteries with cracks, broken
parts, bent or pushed-in / pulled-out contacts).
▶ Do not use the battery as a power source for other unspecified power tools or appliances.
▶ If the battery is too hot to hold, it may be defective.In this case, place the power tool in a non-
flammable location, well away from flammable materials, where it can be kept under observation
and allowed to cool down. Contact HiltiService after the battery has cooled down.
3 Description
3.1 Overview of the product 1
@
Auxiliary grip
;
Switch-on interlock release button
=
On/off switch
%
Grip
&
Charge state and fault display
(
Battery release button
)
Chip collector
+
Pivoting guard operating lever
§
Drive spindle
/
Base plate
:
Pivoting guard
∙
Rip fence (parallel guide)
$
Saw blade position indicator
£
LED / viewing window
|
Hood
¡
Drive spindle lockbutton
Q
Cutting line indicator
W
Parallel guide (rip fence) clamp
E
Battery
R
Clamping lever for cutting depth adjust-
ment
T
Hex. socket wrench
Z
Mounting flange
U
Clamping flange
I
Clamping screw
3.2 Intended use
The product described is a cordless circular saw. It is designed for cutting metal or materials similar to metal.
The use of saw blades not in compliance with the given specification (e.g. diameter, speed of rotation,
thickness) or the use of cutting and grinding discs or blades made from high-alloy steel (HSS steel) is not
permissible. Do not use the saw to cut wood or wood-like materials, plastics, gypsum board, gypsum
fiberboard and composite materials.
▶ Use only Hilti Liion batteries from the B 18 / B 22 series with this product.
▶ Use only Hilti battery chargers of the C4/36 series with these batteries.
3.3 Liion battery display
The charge status of the Li-ion battery and malfunctions of the power tool are indicated by the display on
the Liion battery. The charge status of the Liion battery is displayed after pressing one of the two battery
release buttons.
Status Meaning
4 LEDs light. • Charge status: 75 % to 100 %
3 LEDs light. • Charge status: 50 % to 75 %
2 LEDs light. • Charge status: 25 % to 50 %
1 LED lights. • Charge status: 10 % to 25 %
