Hilti SCM 22-A Original Operating Instructions

6
Status Meaning
1 LED blinks, the power tool is ready for use. • Charge status: < 10 %
1 LED blinks, the power tool is not ready for use. • The battery has overheated or is completely
discharged.
4 LEDs blink, the power tool is not ready for use. • The power tool is overloaded or has overheated.
Note
Battery charge status cannot be displayed while the control switch is pressed and for up to 5 seconds
after releasing the control switch.
If the battery display LEDs blink, please observe the instructions given in the Troubleshooting section.
3.4 Rip fence (parallel guide)
Use of the single arm rip fence allows precise cuts to be made along the edge of the workpiece, or strips of
even width to be cut.
The rip fence can be fitted on either side of the base plate.
3.5 Items supplied
Circular saw, saw blade, hex. socket wrench, parallel guide, operating instructions.
Note
To help ensure safe and reliable operation, use only genuine Hilti spare parts and consumables. Spare
parts, consumables and accessories approved by Hilti for use with the product can be found at your
local Hilti Center or online at: www.hilti.com
3.6 Accessories
Clamping flange, mounting flange, clamping screw.
4 Technical data
4.1 Circular saw
SCM 22A
Weight
8.8 lb
(4.0 kg)
Saw blade diameter
6.3 in … 6.5 in
(160 mm … 165 mm)
Blade disc thickness
0.05 in
(1.2 mm)
Kerf width
0.06 in
(1.6 mm)
Saw blade arbor size
0.8 in
(20 mm)
Rated speed under no load
3,500 /min
Maximum cutting depth
2.2 in
(57 mm)
5 Operation
5.1 Safe operation
CAUTION
Risk of injury! Inadvertent starting of the product.
▶ Remove the battery before making any adjustments to the power tool or before changing
accessories.
Printed: 01.09.2017 | Doc-Nr: PUB / 5292940 / 000 / 00Printed: 01.09.2017 | Doc-Nr: PUB / 5292940 / 000 / 01
