Hilti SCM 22-A User Manual

*2153713*
2153713 English 11
▶ Use only Hilti battery chargers of the C4/36 series with these batteries.
3.3 Liion battery display
The charge status of the Li-ion battery and malfunctions of the power tool are
indicated by the display on the Liion battery. The charge status of the Liion
battery is displayed after pressing one of the two battery release buttons.
Status Meaning
4 LEDs light. Charge status: 75 % to 100 %
3 LEDs light. Charge status: 50 % to 75 %
2 LEDs light. Charge status: 25 % to 50 %
1 LED lights. Charge status: 10 % to 25 %
1 LED blinks, the power tool is
ready for use.
Charge status: < 10 %
1 LED blinks, the power tool is not
ready for use.
The battery has overheated or is
completely discharged.
4 LEDs blink, the power tool is not
ready for use.
The power tool is overloaded or has
overheated.
Battery charge status cannot be displayed while the control switch is
pressed and for up to 5 seconds after releasing the control switch.
If the battery display LEDs blink, please observe the instructions given
in the Troubleshooting section.
3.4 Fence
Use of the single arm fence allows precise cuts to be made along the edge
of the workpiece, or strips of even width to be cut.
The fence can be fitted on either side of the base plate.
3.5 Items supplied
Circular saw, saw blade, hex key, fence, operating instructions.
To help ensure safe and reliable operation, use only genuine Hilti spare
parts and consumables. Spare parts, consumables and accessories
approved by Hilti for use with the product can be found at your local
Hilti Store or online at: www.hilti.group.
3.6 Accessories
Clamping flange, mounting flange, clamping screw.
Printed: 06.06.2019 | Doc-Nr: PUB / 5292940 / 000 / 02
