14 English 2153713
*2153713*
5.1.5 Fitting the saw blade 3
CAUTION
Risk of damage! Unsuitable or incorrectly fitted saw blades may damage
the saw.
▶ Only use blades which are suitable for this saw. Observe the direction-of-
rotation arrow on the saw blade.
▶ Use only saw blades equipped with a rated maximum permissible speed
that is at least as high as the maximum speed stated on the product.
Check that the blade to be fitted complies with the technical
requirements and that it is well sharpened. A sharp saw blade is an
essential requirement for a perfect cut.
1. Clean the mounting flange and the clamping flange.
2. Fit the mounting flange onto the arbor the right way round.
3. Open the pivoting guard.
4. Fit the new saw blade.
Observe the direction-of-rotation arrow on the saw blade and on the
power tool. They must correspond.
5. Fit the outer clamping flange the right way round.
6. Insert the clamping screw.
7. Insert the hex key into the saw blade clamping screw.
8. Press the spindle lock button.
9. Secure the clamping flange with the clamping screw by turning the hex
key in the direction opposite to the direction-of-rotation arrow.
➥ The spindle lock button engages.
10.Before using the power tool, check that the saw blade is correctly seated
and tightened securely.
5.1.6 Adjusting the cutting depth 4
1. Release the cutting depth adjustment clamping lever.
2. Lift the product in a scissor movement and set the desired cutting depth
by closing the clamping lever.
5.1.7 Emptying the chip collector 5
WARNING
Risk of injury! Hot or sharp metal cuttings / chips present a hazard.
▶ Wear protective gloves when emptying the chip collector.
1. Remove the battery.
2. Pull the chip collector away from the tool to the rear.
3. Swing the two halves of the chip collector apart and empty out its
contents.
Printed: 06.06.2019 | Doc-Nr: PUB / 5292940 / 000 / 02
