Hilti TE 3-C User Manual

*2058841*
2058841 English 5
3.2 Intended use
The product described is an electrically powered rotary hammer. It is designed for drilling in concrete,
masonry, drywall / gypsum board, plastic, wood, metal and for driving and removing screws. The product
can also be used for light chiseling work on masonry and surface finishing on concrete.
Hilti products are designed for professional use and may be operated, serviced and maintained only by
trained, authorized personnel. This personnel must be informed of any particular hazards that may be
encountered. The product described and its ancillary equipment may present hazards when used incorrectly
by untrained personnel or when used not as directed.
▶ The tool may be operated only when connected to a power supply providing a voltage and frequency in
compliance with the information given on its type plate.
▶ Observe the national health and safety requirements.
▶ To reduce the risk of injury, use only genuine Hilti tools and accessories.
3.3 Examples of applications 2
The applications shown are possible.
3.4 Items supplied
Rotary hammer, side handle, depth gauge, operating instructions.
For safe, reliable operation, use only genuine Hilti spare parts and accessories. Spare parts,
accessories and consumables approved by Hilti for use with this product can be found at your Hilti
Center or at www.hilti.group.
4 Technical data
When powered by a generator or transformer, the generator or transformer’s power output must be at
least twice the rated input power shown on the rating plate of the power tool. The operating voltage of
the transformer or generator must always be within +5% and -15% of the rated voltage of the power
tool.
The information given applies to a rated voltage of 120 V. The data may vary in the event of deviations
from the rated voltage and for country-specific versions. Please refer to the power tool’s type
identification plate for details of its voltage, frequency, current and input power ratings.
TE 3M TE 3C
Weight
6.8 lb
(3.1 kg)
6.6 lb
(3.0 kg)
Single impact energy
2.5 J 2.5 J
Drilling diameter
range in
concrete/masonry
(hammer drill bit)
5/32 in … 1 1/8 in 5/32 in … 1 1/8 in
Drilling diameter
range in
concrete/masonry
(hammer drill bit)
4 mm … 28 mm 4 mm … 28 mm
Drilling diameter
range in wood (solid)
1/16 in … 3/4 in 1/16 in … 3/4 in
Drilling diameter
range in wood (solid)
1.5 mm … 20 mm 1.5 mm … 20 mm
Drilling diameter
range in metal
(solid-head drill bit)
1/16 in … 1/2 in 1/16 in … 1/2 in
Drilling diameter
range in metal
(solid-head drill bit)
1.5 mm … 13 mm 1.5 mm … 13 mm
Printed: 20.12.2018 | Doc-Nr: PUB / 5245520 / 000 / 04

Hilti TE 3-C Specifications

General

Drilling	Yes
Chuck type	SDS Plus
Product color	Black, Red
Country of origin	Germany
Input power	850 W
Power source	AC
Power plug type	Type C
Impact rate	5160 bpm
Rated speed (max)	1300 RPM
Impact energy (max)	2.5 J
Vibration level (hammer drilling)	15.5 m/s²
Drilling diameter in concrete (max)	28 mm
Optimum drilling diameter (concrete)	6 - 16 mm
Noise level	92 dB
Number of shipping (inner) cases per master (outer) case	1 pc(s)

Weight and Dimensions

Weight	3000 g
Package depth	3456 mm
Package width	2000 mm
Package height	4500 mm
Package weight	4500 g
